MIXERS

PLANETARY

Planetary Mixers from Mixer Systems are the only ones of their type designed and manufactured in the U.S.A. The patented design produces a unique "counter current" mixing action, resulting in a fast, homogeneous mix in as little as 30 seconds.

Planetary Mixer Specifications

Mixing Tank:
Steel all welded construction. Floor is 3/8” thick. Drum wall is 3/16” thick. Tank is welded to an I-beam frame with mounting holes. Frame also has lifting lugs for unloading and handling mixer.

Liners:
Replaceable bolted wall and floor liners of abrasion resistant AR225 (225 Brinell hardness) steel. Floor and walls are 3/8” thick. Optional AR360 (360 Brinell hardness) floor liners are 1/2” thick.

Planetary Mixers

Planetary Mixing Cover:
Hinged access doors with neoprene rubber gaskets. Six hinged access doors. Doors equipped with over-center draw latches of malleable iron with corrosion resistant coating. Cover is bolted to outside of mixer drum and is rotatable 360 degrees.

Safety Electrical Interlocks:
Motor emergency stop station and “cover down” limit switches provided. Ten-second start-up with audible alarm.

Electric Motor:
Dual voltage, 230/460 volt, 3-phase, 60 hertz, 1800 RPM, totally enclosed, fan cooled, cast iron frame. Special voltages available upon request. Motor mounted on adjustable frame with two belt tensioning bolts and four lock-down bolts.

Planetary Mixer Transmission:
Modular Planetary type with heavy duty swing bearing and hardened gears. All components static lubricated. Transmission has a 5 year warranty.

V-Belt Drive:
One banded belt with multiple grooves, fiber-reinforced molded rubber construction.

Mixing Components:
2” diameter formed steel arms with abrasion resistant, replaceable urethane wear guards. Arms are fastened to supports with a 3/4” bolt in a self locking threaded hole. Arm support tubes are 3” diameter and bolted to a rotating case. Inside and outside scrapers are cast Ni-hard segments with slotted mounting to adjust for wear. Cast Ni-hard or rubber paddles are mounted to the mixing arms with 3/4” bolts.

Discharge Door:
Steel door swivels horizontally to provide discharge opening at circumference of mixer. Outer edge of door is supported by steel rail. Door pivots on sealed self-lubricated sleeve bearings retained in cast steel housing. Up to four doors per mixer at 90-degree increments available. Standard is air-operated door with double solenoid valve, air line lubricator and moisture trap. Optional hydraulically operated door available.

Paint:
High grade machinery enamel. Consult factory for special paint types, colors and procedures.

TWIN SHAFT MIXERS

Introducing Mixer Systems NEW 4* and 6** cubic yard output Twin Shaft Mixer. Our Twin Shaft Mixer is designed with off-the-shelf components for ease of service and maintenance, featuring air purge shaft seals, a single drive motor, heavy duty cast steel mixing arms and a hydraulic discharge door. The high volume, high shear mixing action gives you mixing times from 60 to 90 seconds. The Twin Shaft mixer is designed and manufactured in the USA at our facility in Pewaukee Wisconsin.

* based on 164 cu. ft. mixer capacity @ 100 pounds per cubic foot
** based on 245 cu. ft. mixer capacity @ 100 pounds per cubic foot

Twin Shaft Mixer Specifications

Mixing Tank:
Mixing tank is 5/16" thick steel, all welded construction, vertical end walls are 3/4" thick.

Liners:
Drum liners are 3/4" thick, 550 brinnel hardness, cast nihard. Wall liners are 3/8" thick, 225 brinnel hardness.

Mixing Elements:
Cast iron arms, mixing blades and wall scrapers are cast ni-hard, 550 brinell hardness.

Cover:
Four (4) access doors are hinged at the top and sealed with foam rubber gaskets. All access doors are equipped with cover down safety switches which stop the power to the mixer drive if opened while mixer is running. There are two (2) water distribution manifolds inside the cover for even water distribution.

Drive:
A single electric motor, connected to a set of pulley's, drive the solid steel shaft that connects the right angle gear reducers to two (2) planetary drives delivering even power to each of the mixer shafts.

Electric Motor:
One (1) totally enclosed, fan cooled type (TEFC) motor. 460 volt, 3 phase, 60 hertz. Connected to gear box with V-belt drive.

Twin Shafts:
Two (2) 6" square, counter rotating steel mixing shafts; Each shaft is supported by two (2) outboard pillow block bearings and shafts are equipped with air purge seals to prevent mixing chamber leakage.

Discharge Door:
Inverted, roll gate pivots from the bottom and is supported by four (4), end mounted pillow block bearings, two (2) on each end, and is powered by two (2) hydraulic cylinders. Door runs the entire length of the mixer and has a double, rubber seal, and limit switches. Hydraulic power pack includes a 230/460 volts, 60 hertz, 3 phase motor, 5 GPM pump, double solenoid valve, pressure relief valve, 5 gallon reservoir, 10 micron filter, sight glass with thermometer, emergency hand pump with manual shut off valve for manual opening of the discharge door.

Paint:
High grade machinery enamel. Consult factory for special paint types, colors.

Warranty:
Five (5) year, limited warranty on the gear reducer.

Twin Shaft Mixer
